Frequency response:
35Hz – 30kHz (+/- 3dB)
Transducers:
2 x SA1205, 12” LF driver
1 x SA8535M, neodymium HF driver
Cross-over frequency:
1500Hz
Nominal impedance:
16Ω (passive), 4Ω LF (active), 13Ω HF (active)
Sensitivity @ 1W/1m:
97dB (passive), 97dB LF (active), 102dB HF (active)
Max. RMS power:
800W (passive), 800W LF (active), 60W HF (active)
Max. Peak power:
2000W (passive), 2000W LF (active), 1000W HF (active)
SPL program/peak:
126dB/130dB (passive), 126/130dB LF (active), 120/130dB HF (active)
Coverage angles (@ 2kHz H x V):
100° x 40°
Enclosure construction:
30mm thick baffle and walls, 15mm Birch plywood + 15mm MDF
Color:
SA Black Protexture, other colors on request
Connectors:
2 x SpeakOn NL4, 1 x Low / 1 x High (active), 1 x Input / 1 x link (passive)
Physical dimensions (H x W x D):
908mm x 592mm x 420mm (35.8” x 23.3” x 16.6”)
Weight:
80kg (176.4lb)
Warranty:
5 years limited (1 year on ‘moving parts’)
